Tolerance on Thickness of Insulation
The smallest of the measured values of thickness of insulation shall not fall below the nominal value specified in the relevant tables by more than (0.1 mm + 0.1 t1) Where t1 = Nominal Thickness of Insulation in mm.
Tolerance of Thickness of Sheath
The smallest of the measured values of thickness of sheath shall not fall below the nominal value specified in the relevant tables by more than (0.2 mm + 0.2 ts) Where ts = Nominal Thickness of Sheath in mm.
Laying up of core for 2, 3 and 4 core cables
The cores are be laid together with a suitable right hand lay.
Flat 2 and 3 core cable
The cores are laid side by side. In case of 2 core flat cables with Earth continuity conductor the core and the E.C.C are laid side by side in the same plane with E.C.C. occupying the central position.
The smallest of the measured values of thickness of insulation shall not fall below the nominal value specified in the relevant tables by more than (0.1 mm + 0.1 t1) Where t1 = Nominal Thickness of Insulation in mm.
Tolerance of Thickness of Sheath
The smallest of the measured values of thickness of sheath shall not fall below the nominal value specified in the relevant tables by more than (0.2 mm + 0.2 ts) Where ts = Nominal Thickness of Sheath in mm.
Laying up of core for 2, 3 and 4 core cables
The cores are be laid together with a suitable right hand lay.
Flat 2 and 3 core cable
The cores are laid side by side. In case of 2 core flat cables with Earth continuity conductor the core and the E.C.C are laid side by side in the same plane with E.C.C. occupying the central position.
CONSTRUCTION
| Two Core Cables | Red & Black  |
| Three Core Cables | Red, Black & Green |
| Four Core Cables | Red, Yellow, Blue & Green  |
| Five Core Cables | Red, Yellow, Blue, Black & Green |
| Sheath | PVC Type ST-1 of IS : 5831-1984 for Conductor
Temperature 700C PVC Type ST-2 of IS : 5831-1984 for Conductor Temperature 850C |
| Colour of Sheath - | |
| 1.) Non Weatherproof Cables : | Black& White or any colour as per Customer's requirement |
| 2.) Weatherproof Cables : | Black Only |
RETAIL PACKING - STANDARD LENGHT 90 METER (0.5MM2 TO 50 MM2) & 100 METER (70MM2 TO 300MM2).
PROJECT PACKING - 90/180/270 METER OR AS PER CUSTOMER REQUIRMENT.
