Application
Halogen-free single-core wires are used for installation in dry environments for wiring up lighting fixtures and units where valuable assets are to protected from further damage resulting from fire. These cables may be installed on, in and beneath plaster, as well as in closed installation ducts. For use in public places such as: hospitals, schools, museums, airports, bus terminals, shops in general, etc., as well as in computer rooms, offices, production plants, switchboard wiring, laboratories, etc.
Standard
BS EN 50525-3-31.
Technical Data
Nominal Voltage : H05Z1- K UO / U 300 / 500V; H07Z1- K UO / U 450 / 750V
Harmonised Designation : 0.5 mm2 to 1 mm2 - H05Z1- K, 1.5 mm2 to 240 mm2 - H07Z1- K
Temperature Range : -30°C to +70°C
Minimum Bending Radius
Cable diameter < 8 mm: 4 x outer diameter Approx. diameter > 8 to 12 mm: 5 x outer diameter Approx. diameter > 12 mm: 6 x outer diameter Test
Voltage : 2500V
Halogen-free single-core wires are used for installation in dry environments for wiring up lighting fixtures and units where valuable assets are to protected from further damage resulting from fire. These cables may be installed on, in and beneath plaster, as well as in closed installation ducts. For use in public places such as: hospitals, schools, museums, airports, bus terminals, shops in general, etc., as well as in computer rooms, offices, production plants, switchboard wiring, laboratories, etc.
Standard
BS EN 50525-3-31.
Technical Data
Nominal Voltage : H05Z1- K UO / U 300 / 500V; H07Z1- K UO / U 450 / 750V
Harmonised Designation : 0.5 mm2 to 1 mm2 - H05Z1- K, 1.5 mm2 to 240 mm2 - H07Z1- K
Temperature Range : -30°C to +70°C
Minimum Bending Radius
Cable diameter < 8 mm: 4 x outer diameter Approx. diameter > 8 to 12 mm: 5 x outer diameter Approx. diameter > 12 mm: 6 x outer diameter Test
Voltage : 2500V
Cable Construction
Conductor Class 5 flexible plain / metal coated stranded according to EN 60228. Insulation of thermoplastic halogen-free compound type TI7 to EN 50363-7.
Properties
Smoke density to acc. to EN 61034-2. Halogen free acc. to EN 50525-1, EN 60754-1. Corrosivity acc. to EN 60754-2.
Ozone resistant according to EN 60811-2-1 or HD 505.2.1.
Self-extinguishing and flame retardant according to EN 60332-1-2. LSOH = Low Smoke Zero Halogen.
Ozone resistant according to EN 60811-2-1 or HD 505.2.1.
Self-extinguishing and flame retardant according to EN 60332-1-2. LSOH = Low Smoke Zero Halogen.
What is the difference between Low-Smoke and Low-Smoke Zero-Halogen?
There has been a shift in recent years to using
newly developed compounds that emit less harmful gases, particularly
halogens. The term "Low-Smoke Zero Halogen" describes two distinct
properties of a compound. The term "low- smoke" describes the
amount of smoke that a compound emits when burned, while "zero-halogen"
describes the number of halogens used to make the compound. A product can be
low-smoke but not zero-halogen or be zero-halogen but not low-smoke.
However, these terms have typically been used together because the end-user
is interested in cables with both properties.
Increasingly used in public and government buildings and where there is sensitive electronic equipment (i.e. Hospitals, Supermarkets, Airports, Control Rooms & Computer Suites) Low Smoke, Zero Halogen cables are designed for increased safety in the case of a fire, providing :
The European market is demanding that cables used in LANs, WANs, etc. meet LSZH specifications. Historically, most cables used in installations have been insulated with PVC or similar materials. In fires, these insulation materials release chlorine gas. Chlorine is a poisonous gas and a danger to people. In addition, it forms hydrochloric acid when coming into contact with water. Hydrochloric acid can have devastating effects on adjacent equipment. To overcome the problems associated with the release of chlorine gas, halogen-free cables are used. Typically, a halogen-free cable is made of polypropylene, which does not produce a dangerous gas or acid in fire conditions.
Cables intended to fulfil this type of function are often referred to as one of the following :
Both LSZH and LSF are used to limit smoke, fumes, and halogen given off in fire conditions, however, the challenge for buyers is there are no specific standards for LSF cables In the event of a fire, both types will emit very low levels of smoke. LSF cable will emit toxic gases while LSZH will limit the emission of these (typically under 0.5% hydrogen chloride emission). In addition to being toxic, hydrogen chloride is corrosive to equipment. The use of LSZH cables protects both people and limits the amount of equipment damage during a fire situation.
LSF is often a modified PCV with hydrogen chloride additives and while performing better than PVC will give off more smoke and fumes than LSZH. Hydrogen chloride emissions of LSF cable may reach up to 18% Compared with normal PVC cables and LSF, Low Smoke Zero Halogen cables have better fire-retardant properties, low toxic and corrosive gas emissions, and low smoke emission.
Increasingly used in public and government buildings and where there is sensitive electronic equipment (i.e. Hospitals, Supermarkets, Airports, Control Rooms & Computer Suites) Low Smoke, Zero Halogen cables are designed for increased safety in the case of a fire, providing :
- Reduction in hazardous fumes which can cause injury when inhaled
- Reduction in corrosive chemicals which can cause damage to electronics
The European market is demanding that cables used in LANs, WANs, etc. meet LSZH specifications. Historically, most cables used in installations have been insulated with PVC or similar materials. In fires, these insulation materials release chlorine gas. Chlorine is a poisonous gas and a danger to people. In addition, it forms hydrochloric acid when coming into contact with water. Hydrochloric acid can have devastating effects on adjacent equipment. To overcome the problems associated with the release of chlorine gas, halogen-free cables are used. Typically, a halogen-free cable is made of polypropylene, which does not produce a dangerous gas or acid in fire conditions.
Cables intended to fulfil this type of function are often referred to as one of the following :
- LSZH - Low Smoke Zero Halogen
- LSOH - Low Smoke Zero Halogen
- LSF - Low Smoke and Fume
- OHLS - Zero Halogen Low Smoke
Both LSZH and LSF are used to limit smoke, fumes, and halogen given off in fire conditions, however, the challenge for buyers is there are no specific standards for LSF cables In the event of a fire, both types will emit very low levels of smoke. LSF cable will emit toxic gases while LSZH will limit the emission of these (typically under 0.5% hydrogen chloride emission). In addition to being toxic, hydrogen chloride is corrosive to equipment. The use of LSZH cables protects both people and limits the amount of equipment damage during a fire situation.
LSF is often a modified PCV with hydrogen chloride additives and while performing better than PVC will give off more smoke and fumes than LSZH. Hydrogen chloride emissions of LSF cable may reach up to 18% Compared with normal PVC cables and LSF, Low Smoke Zero Halogen cables have better fire-retardant properties, low toxic and corrosive gas emissions, and low smoke emission.
